- Patented Exposed Zero Lock ‘n’ Stop elevation turret
- 30mm Mono-tube chassis
- Fibre Optic Illumination
- Wide Angle FOV
- High volume eyebox
- 100mm eye relief
- High grade, low dispersion Crown glass
- 21 layer Fully Multi-Coated lenses
- Zoom magnification throw lever (removable)
- Fast focus eyebell with lock ring
- Supplied with Professional metal flip-up covers.
Scope Tube
30mm
Magnification
1 - 10x
Objective Lens
24mm
Reticle
MOA FD (10x)
Illumination
11 Levels (Red)
Illumination Control
Stepped Rheostat with Off Positions In-between
Parallax
Fixed
Focal Plane
SFP (Second Focal Plane)
Lens Coating
Fully Multi-Coated - 21 Layers
Optical System
System H7
Field of View
116.3 - 11.6ft @100yds
38.8 - 3.9m @100m
Field of View (°)
21.9 - 2.2
Eye Relief
4in
102mm
PX/Focus
100yds
91m
Click Value
1⁄ 4MOA
Exit Pupil
0.94 - 0.09″
24 - 2.4mm
Turret Type (Elevation)
Zero Lock 'n' Stop, Exposed, Locking, Resettable
Elevation Turret Clicks (max)
135 MOA
Turret Type (Windage)
Exposed, Locking, Resettable
Windage Turret Clicks (max)
135 MOA
Ocular Type
Locking Fast Focus
Power Selector
Knurled Posi-Grip with Removable Zoom Lever
Length
11.1in
283mm
Weight
19oz
540g
